PL103\PL105 – W_DISABLE#\WAKE#
4.2.1. PL103
PL103 Connector’s signals description:
PIN
PIN Name
Description
1
GND
Ground
2
W_DISABLE#
W_DISABLE# function*
*For detailed information on the W_DISABLE# functionality refer to 1VV0301006_xE910
Mini PCIe Adapter HW USER GUIDE \ 1VV0301024_DE910 Mini PCIe Adapter HW
USER GUIDE.
