4.2.2. PL103
PL105 Connector’s signals description:
PIN
PIN Name
Description
1
SMB_DATA
RESERVED
2
SMB_CLK
RESERVED
3
WAKE#
WAKE# function**
4
GND
Ground
**For detailed information on WAKE# functionality refer to 1VV0301006_xE910 Mini PCIe
Adapter HW USER GUIDE \ 1VV0301024_DE910 Mini PCIe Adapter HW USER GUIDE.
