ME910G1 HW Design Guide
1VV0301593 Rev.7 Page 17 of 98 2021-02-02
Mechanical Specifications
Dimensions
The overall dimensions of ME910G1-W1, ME910G1-WW and ME910G1-WWV are:
• Length: 28.2 mm
• Width: 28.2 mm
• Thickness: 2.4 mm
Weight
The nominal weight of the ME910G1-W1 is 3.5 gr.
The nominal weight of the ME910G1-WW and ME910G1-WW is 4 gr.
Temperature Range
Temperature Range
Note
Operating Temperature Range
–40°C to +85°C
The module is fully functional (*) and compliant
according to regulatory standards.
Storage Temperature Range
–40°C to +105°C
The module is not powered and not connected
to power supply
Table 8: Temperature Range
Note: (*) Functional: if applicable, the module is able to make and
receive voice calls, data calls, send and receive SMS and data traffic.
