Telit Wireless Solutions ME910G1-WW - ME910 G1-W1 Connected Mode

ME910G1 HW Design Guide
1VV0301593 Rev.7 Page 27 of 98 2021-02-02
Table 12:GPS Mode *reference signal @-130 dbm with static scenario
Note
:
The reported LTE CAT M1 and LTE CAT NB1 values are an
average among all the product variants and bands for each network
wireless technology.
The support of specific network wireless technology depends on the
product variant configuration.
ME910G1-W1 Connected Mode
Table 13: ME910G1-W1 Connected Mode
Mode
Measure*
(Typical)
Mode Description
GPS
(mA)
Active State
(GNSS ON, CFUN=4)
Acquisition 69.3
GPS+GLO, DPO off
Navigation
22
GPS+GLO, DPO on DWELL=280ms
55.9
GPS+GLO, DPO off
Active State
(GNSS ON, CFUN=5
eDRX)
Acquisition 68.5
GPS+GLO, DPO off
Navigation
15.7
GPS+GLO, DPO on DWELL=280ms
54
GPS+GLO, DPO off
Mode
Measure
(Typical)
Mode
Description
Connected mode
Average
(mA)
Peak
(mA)
CATM
180 400
1 RB, RMC, TBS=5, QPSK, 21dBm,
all bands
NBIoT
245 340 3.75KHz, 1 SC, RU 32ms, TBS=0, BPSK, 20dBm, all bands
65 290
15KHz, 12 SC, RU 1ms, TBS=5, QPSK,
21dBm, all bands
