Telit Wireless Solutions ME910G1-WW - ME910 G1-WW and ME910 G1-WWV Connected Mode

ME910G1 HW Design Guide
1VV0301593 Rev.7 Page 28 of 98 2021-02-02
ME910G1-WW and ME910G1-WWV Connected Mode
Mode
Measure
(Typical)
Mode
Description
Connected mode
Average
(mA)
Peak
(mA)
CATM
380 1100
1 RB, RMC, TBS=5, QPSK, 23dBm,
Band 85, 28, 12
320 900
1 RB, RMC, TBS=5, QPSK,23dBm,
Band 13, 26, 5, 18, 19, 20, 8
305 800
1 RB, RMC, TBS=5, QPSK, 23dBm,
Band 3, 2, 25, 4, 1, 66
NBIoT
240
335
3.75KHz, 1 SC, RU 32ms, TBS=0, BPSK, 20dBm, Band 71
600
1000
3.75KHz, 1 SC, RU 32ms, TBS=0, BPSK, 23dBm, Band 85, 28, 12
500 850
3.75KHz, 1 SC, RU 32ms, TBS=0, BPSK, 23dBm, Band 13, 26, 5,
18, 19, 20, 8
430 750
3.75KHz, 1 SC, RU 32ms, TBS=0, BPSK, 23dBm, Band 3, 2, 25, 4,
1, 66
68 300
15KHz, 12 SC, RU 1ms, TBS=5, QPSK,
21dBm, Band 71
88 950
15KHz, 12 SC, RU 1ms, TBS=5, QPSK,
23dBm, Band 85, 28, 12
78 800
15KHz, 12 SC, RU 1ms, TBS=5, QPSK,
23dBm, Band 13, 26, 5, 18, 19, 20, 8
77 730
15KHz, 12 SC, RU 1ms, TBS=5, QPSK,
23dBm, Band 3, 2, 25, 4, 1, 66
GPRS
300
2000
1TX + 1RX, CS1, GMSK, Band 850, 900
170
1000
1TX + 1RX, CS1, GMSK, Band 1800, 1900
Table 14: ME910G1-WW and ME910G1-WWV Connected Mode
