Telma TL113046 - 2 Telma Installation; Installation Kit TIK10611

TL113046
Installation Manual Ford F650 TELMA AF50-90 SPL100 relay box 124 UIM
Page 4 of 18_____________________________________________________________________________15sep21jh
SECTION 2 RETARDER INSTALLATION
2.1 INSTALLATION KIT TIK10611
PART NUMBER DESCRIPTION QTY
LBA101158
A
F50-90 12V 1480/1550/1610 1
JZ1007XX-45 Rubber mount kit 1
TIB01017 CONTROL/RELAY BOX BRACKET 2
TIB03100 Control Module Bracke
t
1
TIB03104 UNIVERSAL CHASSIS BRACKET 2
TIB03107
TOP WASHER FOR AXIAL RETARDER BRACKET 4
TIB07010
A
F5 retarder bracket - Zero De
g
rees 2
TID15005 HARNESS ASSEMBLY 8G_2G TRCM2 with rela
y
box 124 1
TID31020 UIM C
A
N harness 1
TID31015 CAN extension harness 1
TIF01064 hex head bolt 1/4 - 28 x 1.25
g
rade 8
y
ellow zinc for TRCM mountin
g
2
TIF01066 n
y
lon insert locknut 1/4-28UNF for TRCM mountin
g
2
TIF03001 all metal lock nut 3/8-24UNF 16
TIF05010 LOCKWASHER 5/16 SPLIT 4
TIF05011 NUT 5/16 4
TIF05012 BOLT 5/16-18UNC x 1-3/4 HEX HEAD G5 4
TIF05013 BOLT 1/2-13UNC x 1-1/2 HEX HEAD G5 2
TIF05014 LOCKWASHER 1/2 MED SPLIT 2
TIF05025 5/8-18 x 2 GRADE 8 HEX FLANGE CAP SCREW 2
TIF05026 5/8-18 GRIP FLANGE LOCKNUT 2
TIF05031 1/2 - 20 X 1.75 flan
g
ed head bolt 8
TIF05032 1/2 - 20 flan
g
ed nu
t
8
TIF07001 M12 x 1.75 x 35 Grade 10.9 DIN 933 Black Phosphate 200+ Salt 6
TIG11010 TELMA LIGHT BAR DISPLAY 1
TIG31075 TRCM2a control module 1
VF201382 Trep Washer 6
Note1: SPL90 flange yokes 2 x Spicer part number 90-2-19 must be ordered separately.
