3.10 RH Menu
The RH (Radio Head) menu includes the following options:
 General
 Ports
3.10.1 General
The RH General menu enables viewing the following read-only general radio head properties:
 Installed RH Type: RH Type is in the format rhAAAABBBBZZZWPPRbyTCO, where:
» AAAA = Lower bound of frequency band in MHz, rounded up to the nearest integer.
» BBBB = Upper bound of frequency band in MHz, rounded down.
» ZZZ = always 000 in TDD systems.
» W = always N in TDD systems.
» PP = maximum transmit power in dBm, rounded down.
» R = number of receive channels.
» T = number of transmit channels.
» C = Y if cavity filter or a gap in the band is present, N if not.
» O = Reserved (0).
 Serial Number
The RH General menu also enables viewing/updating the following parameter:
INFORMATION
In the current release the following Radio Head Types are supported:
 COMPACT -
» rh34003675000N274by4N0 (3400-3675 MHz, 27 dBm, 4Rx by 4Tx)
» rh34003600000N304by4N0 (3400-3600 MHz, 30 dBm, 4Rx by 4Tx)
» rh33003800000N304by4N0 (3300-3800 MHz, 30 dBm, 4Rx by 4Tx)
» rh34003700000N304by4N0 (3400-3700 MHz, 30 dBm, 4Rx by 4Tx)
» rh33003500000N304by4N0 (3300-3500 MHz, 30 dBm, 4Rx by 4Tx)
» rh36003800000N304by4N0 (3600-3800 MHz, 30 dBm, 4Rx by 4Tx)
 COMPACT HP (High Power):
» rh34003600000N384by2N0 (3400-3600 MHz, 37 dBm, 2Rx by 2Tx)
