Table 3-4: Functionality of Allowed Ducting Mitigation Modes, 5/10 MHz BS Bandwidth
Configured
Total Uplink
Duration
(slots)
Mitigation
Mode
Maximum Cell
Radius (Km)
Extra TTG
(symbols)
Added DL
Silenced
Symbols
Actual
Uplink
Duration
(slots)
DL
Symbols
4 None 1, 2, 4, 8 0 0 5 34
15, 23, 30 2 0 4 32
Medium N/A
High N/A
5 None 1, 2, 4, 8, 15, 23 1 0 5 30
30 3 0 5 28
Medium 1, 2, 4, 8 0 4 4 30
15, 23 2 2 4 30
30 2 4 4 28
High N/A
6 None 1, 2, 4, 8 0 0 6 28
15, 23, 30 2 0 6 26
Medium 1, 2, 4, 8 1 2 5 28
15, 23 1 4 5 26
30 3 2 5 26
High 1, 2, 4, 8 0 6 4 28
15, 23, 30 2 6 4 26
7 None 1, 2, 4, 8, 15, 23 1 0 7 24
30 3 0 7 22
Medium 1, 2, 4, 8 0 4 6 24
15, 23 2 2 6 24
30 2 4 6 22
High 1, 2, 4, 8, 15, 23 1 6 5 24
30 3 9 5 22
