BreezeCOMPACT System Manual
Chapter 1 - System DescriptionSpecifications
Chapter 1 - System Description Specifications
18
1.4.5 Environmental
1.4.6 Mechanical and Electrical
1.4.6.1 COMPACT
1.4.6.2 COMPACT HP
Table 1-5: Environmental Specifications
Typ e Details
Operating Temperature -40°C to 55°C
Operating Humidity 5%-95%, weather protected
Table 1-6: Mechanical & Electrical Specifications, COMPACT units
Item Description
Dimensions 242.7 x 343 x 166.9 mm
Weight 8.2 Kg
Power Input -40 to -60 VDC
Power Consumption 27 dBm units: 105W maximum (at 70% Tx/Rx duty cycle),
125W peak.
30 dBm units: 118W maximum (at 70% Tx/Rx duty cycle),
142W peak.
Table 1-7: Mechanical & Electrical Specifications, COMPACT HP units
Item Description
Dimensions 280 x 510 x 220 mm
Weight 19.5 Kg
Power Input -40 to -60 VDC
Power Consumption 186W maximum (at 70% Tx/Rx duty cycle), 225W peak
