 Bandwidth
 Center Frequency
 TX Power
Using the Management System
Select Sector 1, in the Radio Cluster section configure the Bandwidth, Center Frequency and TX Power
parameters of Radio Cluster 1 and click Apply.
2.5.4 Configuring Antenna Associations
Using the Monitor Program
Select Sector>Antenna Association>Add.
You will be prompted to configure the following parameters:
 RF Port Number: Enter 1.
 Antenna Number: Enter the relevant Antenna Number as configured in the Antenna menu.
 Antenna Port Number: Enter the relevant Antenna Port Number.
Repeat the Antenna Association configuration for RF Port Number 2 to 4.
Using the Management System
In the Association section of Sector 1 screen click Add Association and enter the relevant Antenna
Number and Antenna Port Number for RF Port 1.
Repeat the process for RF Port Number 2 to 4.
Click Apply.
2.5.5 Applying the Configuration
To apply the changes, reset the unit:
In the Monitor program, select BTS>Unit Control>ShutDown Operation>Update and select the reset
option for the Shutdown Operation parameter.
In the management system, select the Equipment>Chassis screen. In the Shut Down Operation section
select the Reset option for the Shut Down Type parameter and click Apply.
