3.7.2.6 Connectivity
The Connectivity menu includes the following options:
 Bearer Interface
 Authentication
 QOS Marking Rules
 ASN-GW Load Balancing
3.7.2.6.1 Bearer Interface
The Bearer Interface menu enables viewing/updating the values configured for the following
parameters:
 IP Address
 Default Gateway Connectivity Status
3.7.2.6.1.1 IP Address
The IP address of the bearer interface of the BS. Must be unique in the network.
A change in Bearer IP Address will take effect after next reset.
Table 3-5: Functionality of Allowed Ducting Mitigation Modes, 7 MHz BS Bandwidth
Configured
Tot al
Uplink
Duration
(slots)
Mitigation
Mode
Maximum Cell
Radius (Km)
Extra TTG
(symbols)
Added
DL
Silenced
Symbols
Actual
Uplink
Duration
(slots)
DL
Symbols
3 None 1, 2, 4, 8, 15, 23, 30 1 0 3 22
Medium N/A
High N/A
4 None 1, 2, 4, 8, 15, 23 0 0 4 20
30 2 0 4 18
Medium 1, 2, 4, 8, 15, 23 1 2 3 20
30 1 4 3 18
High N/A
5 None 1, 2, 4, 8, 15, 23, 30 1 0 5 16
Medium 1, 2, 4, 8, 15, 23 0 4 4 16
30 2 2 4 16
Long 1, 2, 4, 8, 15, 23, 30 1 6 3 16
