1.4.7 Antennas
1.4.7.1 Attached, 3.3-3.8 GHz, 4 Ports 65º Double Dual Slant (xx)
Applicable only for COMPACT installations.
Table 1-8: Attached Antenna 3.3-3.8 DDS 65º (P.N. 300726) Specifications
Item Description
Frequency Band (MHz) 3300-3800
Number of Elements 4
Polarization Linear, +/-45°
Gain (dB) 18
Azimuth Beamwidth (degrees) 65
Elevation Beamwidth (degrees) 6.5
Maximum Power (W) 150
Cross-polarization Discrimination (dB) >15
Front-to-Back Ratio (dB) >30
Electrical Downtilt Range (degrees) 0
Isolation Between Ports (dB) >30
Return Loss (dB) >15
RF Interface Impedance (Ohm) 50
RF Connectors 4 x N-Type jacks with RF cable tails
Dimensions (mm) 720x 266 x 52
Weight (Kg) 4
Regulatory Compliance RoHS Compliance
