BreezeCOMPACT System Manual
Chapter 3 - Operation and AdministrationBS Menu
Chapter 3 - Operation and Administration BS Menu
75
3.7.2.6.1.2 Default Gateway Connectivity Status
Read-only. The status of connectivity with the default authenticator: unknown, up, down. The keep-alive
mechanism starts only after first registration at the ASN-GW. Until then this mechanism is disable and
connectivity status is unknown.
3.7.2.6.2 Authentication
The Authentication menu enables viewing/updating the values configured for the following parameter:
3.7.2.6.2.1 Threshold - Active MSs
The threshold for the number of MSs in active operation state (not Idle) served by the BS. Exceeding this
threshold sets the alarm “Excessive MS number”.
The range is 0-512. When set to 0, the alarm is disabled. The default is 512.
3.7.2.6.3 QOS Marking Rules
The QoS Marking Rules menu includes the following options:
Internal ASN Traffic QOS Rules
Internal Management Traffic QOS Rules
QOS Rules
3.7.2.6.3.1 Internal ASN Traffic QOS Rules
The Internal ASN Traffic QOS Rules menu enables viewing/updating the values configured for the
following parameters:
Intra ASN DSCP
802.1p Priority
3.7.2.6.3.1.1 Intra ASN DSCP
DSCP priority value to be used for marking of intra-ASN (R8/R6) traffic. The range is 0-63. The default is
0.
A change in Diffserve Code Point will take effect after next reset.
3.7.2.6.3.1.2 802.1p Priority
802.1p priority value to be used for marking of intra-ASN (R8/R6) traffic. The range is 0-7. The default is
0.
A change in 802.1p Priority will take effect after next reset.
3.7.2.6.3.2 Internal Management Traffic QOS Rules
The Internal Management Traffic QOS Rules menu enables viewing/updating the values configured for
the following parameters:
Diffserv Code Point
802.1p Priority
