For each of the four ports, the following options for the Shutdown Power Port # (1-4) parameter are
available:
shutDown: Select to shut down power to the port.
noShutDown: Normal operation.
rxOnly: Disable transmission on the port (enable only receive functionality).
The default status for all ports is normal operation (noShutDown).
A change in Shutdown Power Port # parameter will take effect after next reset.
In the current release the following configuration options are applicable:
1 4Rx by 4Tx -: All 4 ports should be configured for Tx/Rx operation (noShutDown).
1 4Rx by 2Tx (4x2) configuration: 2 ports should be configured for Tx/Rx operation (noShutDown), and
the 2 other ports should be configured for Rx Only operation (rxOnly). Different antenna polarities
should be connected to the 2 Tx/Rx ports.
2 2Rx by 2Tx (2x2) configuration (applicable for both COMPACT and COMPACT HP): 2 ports should be
configured for Tx/Rx operation (noShutDown), and the 2 other ports should be disabled (shutDown).
Different antenna polarities should be connected to the 2 Tx/Rx ports.
Refer to Installed RH Type (in “RH Menu” on page 88) for details on ports configuration supported by
each Radio Head.
