Telstra Smart Modem 3 - Page 13

Wi-Fi
PHONE
WAN/DSL
MOBILE
SIGNAL
RESET
SIM
4
3
2
2
LAN 1
PRI
DIV
POWER
PHONE 1
USB 2.0
DSL
1
2
3
4
Have a phone?
Connect via your
existing phone cable.
Prefer a wired connection?
Have a computer or
a wired home network?
Connect using your
own ethernet cable.
Once connected,
the light will show
solid green on the
front of modem.
Connected!
ON/OFF PWR E SC/APC
Indoor device
Connect the cable
to the yellow
connection port.
Outdoor device
Connect the cable
to the wall socket or
connection point.
Note:You’ll either have an Indoor device or Outdoor device installed in your premises.
