3.4.3 FMA1YX/FM11YX IO Elements
For FMA1YX/FM11YX devices first ID number is always “2”, second and third ID numbers refers
to specific CAN-CONTROL IO element (Table 3). And the last ID number refers to sections –
Property; Generation Type; Low level, High level and Averaging Constant (Table 4).
Here’s example: ID 2013 – configures Accelerator Pedal position parameter “High Level”
Table 3 CAN-CONTROL IO elements SMS configuration Ids range
CAN-CONTROL IO Element Parameter Ids range
Speed 2000-2004
Accelerator pedal position 2010-2014
Total fuel used 2020-2023
Fuel level (liters) 2030-2034
Engine RPM 2040-2044
Total mileage 2050-2053
Fuel level (percent) 2060-2064
Program number 2070-2073
Module ID 2080-2083
Total Mileage (counted) 2110-2113
Fuel Consumed (counted) 2120-2123
Engine Temperature 2170-2174
Control State Flags 2230-2233
Security State Flags 2320-2323
Table 4 CAN-CONTROL IO parameters configuration
Parameter ID Parameter name Available values
2xx0 Priority 0 – IO element disabled
1 – Low priority
2 – High priority
3 – Panic priority
2xx1 Generation type 0 – Event on exit
1 – Event on entrance
2 – Event on both
3– Monitoring
4 – Hysteresis
5 – On change
2xx2 Low level
2xx3 High Level
2xx4
Averaging
Constant
From 0 to 2
