Teltonika FMC650 - Page 14

Quick Manual v1.1 // FMC650
14
Telematics
Data transfer
LTE FDD: Max 10Mbps (DL)/Max
5Mbps (UL) LTE TDD Max 8Mbps
(DL)/Max 2Mbps (UL) GPRS:
Max 85.6Kbps (DL)/Max 85.6Kbps
(UL)
Data support SMS (text/data)
Transmit power
Class 4 for GSM850/900: 33±2dBm
Class 1 for GSM1800/1900:
30±2dBm
Class 3 for LTE-TDD: 23±3dBm
Class 3 for LTE-FDD: 23±3dBm
Bluetooth LE: up to 8dBm
POWER
Input voltage range
8 - 32 V DC with overvoltage
(compatible with pulse 5a and pulse
5b) and reverse polarity protection
Back-up battery 550 mAh 8,4V Ni-MH battery
Internal fuse 3 A, 125 V
2 W max.
Current
consumption at 12 V
GPRS: average 60 mA
Nominal: average 45 mA (with no
load)
GNSS sleep: average 32 mA
Deep Sleep: average 4 mA
Online Deep Sleep: average 11 mA
Full Load/Peak: <0.25A Max
2 W max.
Current
consumption at 24 V
GPRS: average 35 mA
Nominal: average 24 mA (with no
load)
GNSS sleep: average 17 mA
Deep Sleep: average 2,9 mA
Online Deep Sleep: average 7 mA
Full Load/Peak: <0.25A Max
INTERFACE
Digital Inputs 4
Digital Outputs 4
Analog Inputs 4
1-Wire temperature
sensors
6
1-Wire iButton 1
RS232 2
RS485 1
CAN J1939 2
J1708 1
K-Line 1
LVCAN/ALLCAN 1
GNSS antenna External High Gain
GSM antenna External High Gain
USB 2.0 Mini-USB
LED indication 2 status LED lights
SIM Micro-SIM
SIM 2x SIM Card (Dual-SIM)
Memory
16MB internal ash memory and
external SD card up to 32 GB.
Switchable CAN
terminators
Supported on CAN1 and CAN2 lines
