Quick Manual v1.1 // FMC650
17
Telematics
CHARACTERISTIC
DESCRIPTION
VALUE
SUPPLY VOLTAGE MIN. TYP. MAX. UNIT
Input resistance (DIN4) 15
kΩ
Input voltage
(Recommended
Operating Conditions)
0
Supply
voltage
V
Input Voltage threshold
(DIN1, DIN2, DIN3,
DIN4)
7.5 V
ANALOG INPUT
Input Voltage
(Recommended
Operating Conditions),
Range 1
0 +10 V
Input resistance 120 kΩ
Input Voltage
(Recommended
Operating Conditions),
Range 2
0 +30 V
Input resistance 147 kΩ
1-WIRE
Supply voltage +3.3 +3.9 V
Output inner resistance 7 Ω
Output current (UOUT>
3.0 V)
30 mA
CHARACTERISTIC
DESCRIPTION
VALUE
SUPPLY VOLTAGE MIN. TYP. MAX. UNIT
Short circuit current
(UOUT> 0 V)
75 mA
CAN INTERFACE
Internal terminal
resistors CAN bus
120 Ω
Dierential input
resistance
19 30 52 kΩ
Recessive output
voltage
2 2.5 3 V
Dierential output
voltage
0.5 0.7 0.9 V
Common mode input
voltage
-30 30 V
