LOGIN TO DEVICE
1. To enter the router's Web interface (WebUI), type http://192.168.1.1 into the URL field of your Internet browser.
2. Use login information shown in image A when prompted for authentication.
3. After you log in, you will be prompted to change your password for security reasons. The new password must
contain at least 8 characters, including at least one uppercase letter, one lowercase letter, and one digit. This step is
mandatory, and you will not be able to interact with the router's WebUI before you change the password.
4. When you change the router's password, the Configuration Wizard will start. The Configuration Wizard is a tool
used to set up some of the router's main operating parameters.
5. Go to the Overview page and pay attention to the Signal Strength indication (image B). To maximize the cellular
performance try adjusting the antennas or changing the location of your device to achieve the best signal
conditions.
A. B.
admin
admin01
Bytes received/sent*
SIM card slot in use
Data connection state
State
-65 dBm
Connected
Registered (home); OPERATOR; 4G (LTE)
Ready
348.7 KB / 223.5 KB
TECHNICAL INFORMATION
*Order code dependent.
**Higher gain antenna can be connected to compensate for cable attenuation when a cable is used. The user is responsible for the compliance with the legal regulations.
Radio specifications
Bundled accessories specifications*
RF technologies
Max RF power
3G, 4G, GNSS
24 dBm@WCDMA, 23 dBm@LTE
Mobile antenna
GNSS antenna
698~960/1710~2690 MHz, 50 Ω, VSWR<3, gain** 3 dBi, omnidirectional, SMA male connector
1575.42~1602 MHz, 2.2~5 VDC, VSWR<1.5, active total gain** 28 dB (typ.), RHCP polarization, SMA male connector
Power adapter Input: 0.6A@100-240VAC, Output: 12VDC, 1.5A, 4-pin plug
