Tempress Systems TS-8603 - 2.2 Components of the furnace

DESCRIPTION
A: top view of the furnace with scavenger
1: Water outlet Bulkhead Swagelok (furnace cooling)
2: Water inlet Bulkhead Swagelok (furnace cooling)
3: Exhaust Furnace
4: Water outlet Bulkhead Swagelok (cooling vacuum-flanges)
5: Water inlet Bulkhead Swagelok (cooling vacuum-flanges)
6: Exhaust scavenger-box
7: Exhaust scavenger-housing
B: sideview of the furnace
C: frontview of the furnace
8: Scavenger box exhaust.
9: Tube switch
10: Key switch control power on-off
11: Mainswitch (lockable in off-position)
12: Mainpowerconnection
13: Excess Temperature Controller
D: view of the loadside of the furnace
8: Scavenger-box exhaust
E: rearside of the furnace
8: Scavenger-box exhaust
2.2 Components of the furnace
• Furnace cabinet
• Scavenger
• Cooling unit
• Fast Cool down
• Heating elements
• Tube (support and sealing)
• Flange
• Furnace Temperature Control
• Power supply
• Main switch assembly
