MAINTENANCE
5.Maintenance
5.1 Introduction
With this system, maintenance is reduced to a minimum. It is only necessary on the rare
occasion when a part fails. Replacement of parts is described in the following paragraphs.
5.2 Heating Element Coil
The heating element must be replaced by a new one, when it is out of order.
Preceding the installation of a new heating element, remove the quartz tube and
thermocouples first (take it out of the furnace).
After installation, beware of following the procedure, described in item 4.2 again.
Installation of a new heating element (exchange of the heating element) must be
done in the following order:
Turn-off power to tube level (using the tube switch).
Place safety marker on tube switch, preventing someone switching on again (meet
customers facility safety requirements).
Close the ballvalves in the gassource cabinet at shelve (tube) level.
Remove outer panel at tube level, by turning the DZUS-fasteners at the left- and
right side of the panel.
Open 'tunnel' in front of heating element in which the thermocouple wires are
connected.
Disconnect the clamp spring of the connected thermocouples.
Disconnect the thermocouple wires from, these thermocouples.
Withdraw carefully, using gloves, and place them at a safe and clean place to prevent
damage and remove the insulating cord (see Figure 4-3, page 4-5).
Disconnect the gas inlet line to the process tube.
Remove the frontflange assembly (only mounted for LPCVD) and when present,
also the backflange.
Remove process tube from the furnace tube level (using gloves) and put it at a safe
and clean place.
Remove tube adapters and the tube support.
Remove the front support of the heating element, when necessarily.
Disconnect the thermocouple-connection cables from the terminal blocks.
Remove 'tunnel' from the thermocouples.
Bend the compensation cables from the thermocouples carefully to the side.
FURNACE REFERENCE MANUAL
5-1
