Tenda AC7 User Manual

77
− The WAN IP address of the router: 102.33.66.88.
Please ensure that router obtains an IP address from the public network. This function may not work
on a host with an IP address of a private network or an intranet IP address assigned by ISPs that start
with 100. Common IPv4 addresses are classified into class A, class B and class C. Private IP addresses of
class A range from 10.0.0.0 to 10.255.255.255; Private IP addresses of class B range from 172.16.0.0-
172.31.255.255; Private IP addresses of class C range from 192.168.0.0-192.168.255.255.
Configuring procedures:
Step 1 Start a web browser on a device connected to the router and visit tendawifi.com to log in
to the web UI of the router.
Step 2 Set the server host as the DMZ host.
1. Choose Advanced > DMZ Host.
2. Set DMZ Host to Enable.
3. Enter the IP address of the host, which is 192.168.0.136 in this example.
4. Click OK on the bottom of the page.
Step 3 Assign a fixed IP address to the host where the server locates.
1. Choose Advanced > IP-MAC Binding.
2. Enter the IP Address for the FTP server host, which is 192.168.0.136 in this example.
FTP server
− IP: 192.168.0.136
− MAC: D4:61:DA:1B:CD:89
− Port number: 21
WAN IP：102.33.66.88
Access using an
IP address
Smart phone
Computer

Tenda AC7 Specifications

General

VPN support	IPsec pass through, PPTP pass through, L2TP pass through, PPTP server, PPTP client, L2TP client
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
USB port	No
Ethernet LAN (RJ-45) ports	4
Transmit power	30 dBmW
Antennas quantity	5
Antenna gain level (max)	6 dBi
Product type	Tabletop router
Product color	Black
LED indicators	LAN, System, WAN
Output current	1 A
Output voltage	9 V
AC input voltage	100 - 240 V
Power source type	AC
AC input frequency	50 - 60 Hz
Package type	Box
Package weight	860 g
Number of products included	1 pc(s)
Wi-Fi band	Dual-band (2.4 GHz / 5 GHz)
Wi-Fi standards	802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac)
Top Wi-Fi standard	Wi-Fi 5 (802.11ac)
WLAN data transfer rate (max)	867 Mbit/s
WLAN data transfer rate (first band)	300 Mbit/s
Firewall security	Forbid UDP flood attack, Forbid TCP flood attack, Forbid flood attack, Forbid WAN PING from internet
Security algorithms	WPA, WPA-PSK, WPA2, WPA2-PSK, WPS
Certification	CE, FCC, RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %
Cables included	LAN (RJ-45)

Weight and Dimensions

Depth	141.5 mm
Width	220 mm
Height	49 mm
Weight	360 g
