Tenda AP Series User Manual

❸
Option A: Knock the plastic anchors (Length: 26.4 mm;
Diameter: 2.4 mm) into the holes using the rubber hammer.
Insert the screws (Length: 25 mm; Diameter: 3 mm) into the
screw holes on the bracket and fix them into the plastic
anchors using a screwdriver to fix the bracket.
Option B: Insert the screws (Length: 25 mm; Diameter: 3 mm)
into the screw holes on the bracket and fix them into the plastic
nuts (Length: 14.5 mm; Diameter: 2.51 mm) using a screwdriver
to fix the bracket.
❹
Use a CAT5e or better Ethernet cable to connect a PoE power
supply device to the LAN/PoE port of the AP.
- 5 -
Screw
Plastic Anchor
Mounting Bracket
Mounting Bracket
Screw
Plastic Nut

Tenda AP Series Specifications

General

Model	AP Series
Category	Wireless Access Point
Frequency Range	2.4GHz/5GHz
Wireless Standards	IEEE 802.11a/b/g/n/ac
Wireless Speed	Up to 1200Mbps
Operating Mode	Repeater
Security	WPA/WPA2-PSK
Antenna	External antennas
Operating Temperature	0°C to 40°C
Storage Temperature	-40°C to 70°C
Operating Humidity	10% to 90% non-condensing
Storage Humidity	5% to 95% non-condensing
