Option B Connect to other PoE power supply
devices
Tips
The maximum power supply distance is 100 meters.
Tips
The AP supports power supply through standard PoE devices. The PoE
power supply device should be compliant with IEEE 802.3at standard.
Use an Ethernet cable to connect the LAN/PoE port of the AP to
a PoE power supply device. A PoE switch is used for illustration in
the following figure.
PoE switch
AP
≤100m
LAN port
used to connect to other network devices
PoE port
≤100m
❶
❷
- 7 -
