Tenda D305 User Manual

9
Chapter 3 Internet Setup
Internet setups are detailed in this part, which include connection types, link types and wireless security setup, etc.
This part includes the following:
3.1 Log in to UI
3.2 Set up Internet
3.3 Quick Wireless Security Setup
3.1 Log in to UI (User Interface)
To configure the parameters of the modem router, you should log in to its UI (User Interface) first.
① Set your PC to Obtain an IP address automatically. For more information, see Appendix 2 Configure Your PC.
② Launch a web browser and enter 192.168.1.1 to display the login window.
③ Enter admin in both the login User Name and Password fields if you access the router for the
first time and then click Login to enter the home page.
_________________________________________
TIP
If you forgot your login user name and password,
press the WPS/RST button on the device for about
8 seconds to reset the router, and then re-log in with
the default user name and password “admin”.
_________________________________________

Tenda D305 Specifications

General

Wi-Fi band	Single-band (2.4 GHz)
Wi-Fi standards	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Top Wi-Fi standard	Wi-Fi 4 (802.11n)
WLAN data transfer rate (max)	300 Mbit/s
Antennas quantity	4
Antenna gain level (max)	5 dBi
Ethernet LAN	Yes
Cabling technology	10/100Base-T(X)
Networking standards	IEEE 802.11n, IEEE 802.1Q, IEEE 802.1p, IEEE 802.3, IEEE 802.3u
Ethernet LAN data rates	10, 100 Mbit/s
Ethernet LAN interface type	Fast Ethernet
Memory card slot(s)	No
RJ-11 ports quantity	1
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	3
Product type	Tabletop router
Product color	Black
LED indicators	DSL, LAN, Power, System, USB, WLAN, WPS
Output current	1 A
Output voltage	12 V
AC input voltage	100 - 240 V
Power source type	DC
AC input frequency	50 - 60 Hz
Cables included	LAN (RJ-45), Phone (RJ-11)
Security algorithms	64-bit WEP, 128-bit WEP, WPA-PSK, WPA2-PSK, WPS
Certification	CE, FCC, RoHS
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	125 mm
Width	190 mm
Height	26.5 mm
