2. Connect and register the ONT
Connect the ONT as shown in the figure. Wait until the PON LED
indicator lights solid on, then the ONT is registered successfully.
ONT
DO NOT look directly at the PON port when the device is powered on,
as well as the terminal of the indoor fiber cord, to prevent any harm to
your eyes.
Caution, laser
If your ISP provides any parameters for registration, you can use them
to manually register the ONT.
Method:
➊ Use an Ethernet cable to connect a LAN port of the ONT to a wired
device, such as a computer.
➋ Enter 192.168.1.1 in a web browser and log in to the web UI of the
ONT (default user name and password are both admin).
➌ Navigate to Admin > GPON Settings (or EPON Settings) and
enter the parameters provided by your ISP.
Tips
PWR PON LOS LAN
PON LAN RST PWR
Internet
Power adapter
Fiber cord
1
2
