Tenda O1 User Manual

144
The added rule displays in the bandwidth control list. The parameters on the picture below are
used for examples.
Parameters description
Name
Description
Remark
It specifies the additional information of the bandwidth control rule. This field is
required. For convenient management, you’d better specify different remarks for
different rules.
IP Address Range
It specifies the IP address or IP address range of devices that this rule applies to.
If you want to control only one device, enter the same IP address in the two boxes. If
you want to control multiple devices, enter an IP address range including start IP
address and end IP address. The end IP address should be greater than the start IP
address.
Max. Upload Rate
It specifies the maximum upload/download rate of the device whose IP address is
within the IP Address Range.
Max. Download Rate
Status
It specifies the current status of the rule. You can enable or disable it as required.
Action
Click to delete the rule.
8.3.2 Example of configuring bandwidth control
Networking requirement
The CPE is used to bridge to the ISP hotspot for internet access in a house in the countryside, and
the device is set to WISP mode. To ensure that every device can access the internet smoothly, you
want to specify a maximum upload/download for each device.
Assume that: The maximum upload rate of each device connected to the WiFi network of the
device is 5 Mbps, and download rate is 10 Mbps. And the IP address range of the devices
connected to the WiFi network is 192.168.2.100 to 192.168.2.200.

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
