Tenda O1 User Manual

147
----End
If internet users still cannot visit servers in LAN after the configuration, try the following solutions:

Ensure that the WAN IP address of the device is a public IP address, and the internal port you
entered is correct.

Security software, antivirus software, and the built-in OS firewall of the computer that establishes a
server may cause port forwarding function failures. Disable them and try again.
The added rule displays in the port forwarding list. The parameters on the picture below are used
for examples.
After the port forwarding rule takes effect, to access the LAN server:
Enter Protocol name://WAN port IP address:External port in the address bar of a web browser on
a computer over the internet.
Parameters description
Name
Description
Internal IP Address
It specifies the IP address of the host that establishes a server in LAN.
Internal Port
It specifies the service port of the server in LAN.
After you select an Application, this option will be auto populated. You can also
customize it.

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
