Tenda O1 User Manual

152
----End
The added rule displays in the MAC filter list. The parameters on the picture below are used for
examples.
Parameters description
Name
Description
Mode
It specifies the mode of MAC filter rule.

Disable: Disable the MAC Filter function.

Allow: Allow the devices with the MAC addresses in the list to access the internet
via this device, and disallow the other devices to access the internet via this device.

Disallow: Disallow the devices with the MAC addresses in the list to access the
internet via this device, and allow the other devices to access the internet via this
device.
Remark
It specifies the additional information of the rule.
MAC Address
It specifies the MAC address of the device to which the rule applies.
Time
It specifies the period at which the rule takes effect.

Tenda O1 Specifications

General

5 GHz	No
Bandwidth	2.4 GHz
Networking standards	IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Maximum data transfer rate	300 Mbit/s
Placement	Wall
Certification	FCC/CE/RoHS
Product color	White
LED indicators	LAN, PoE, WLAN
International Protection (IP) code	IP64
Output voltage	9 - 12 V
Power consumption (max)	2.6 W
Security algorithms	WEP, WPA-PSK, WPA2-PSK
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
Antenna features	Integrated antenna
Cables included	LAN (RJ-45)
Storage temperature (T-T)	-40 - 70 °C
Operating temperature (T-T)	-30 - 55 °C
Operating relative humidity (H-H)	10 - 90 %

Weight and Dimensions

Depth	67.5 mm
Width	80 mm
Height	190.35 mm
