40
2.
3.
Set the rotary switch to measurement mode,
the Meter may display a fixed reading which is a
internal distributed capacitor value. For best accuracy
when testing capacitors less than 10nF, the internal
distributed capacitor value should be subtracted from
the reading.
To improve the measurement accuracy of small value
capacitors (less than 10nF), press REL with the
test leads open to subtract the residual capacitance
of the Meter and leads.
It is recommended that the short test clip leads be
used for capacitance measurement.
Note
The LCD displays OL indicating the tested capacitor
is shorted or it exceeds the maximum range.
Capacitors larger than 400µF take longer time. The
analogue bar graph shows the time left before
finishing the measurement.
l
l
l When capacitance measurement has been
completed, disconnect the connection between the
test leads and the circuit under test and remove test
leads from the input terminals of the Meter.
Model 72-7730A/72-7732A: OPERATING MANUAL
