Tenma 72-7730A - Physical Specifications

54
z
z
Physical Specifications
Display (LCD)
Operating Temperature
Storage Temperature
Relative Humidity
Battery Type
Electromagnetic Compatibility
Dimensions (H x W x L)
Weight
Primary display: 40,000 counts (model 72-7732A), 20,000 counts (model 72-7730A),
Updates 2-3 times / second,
Two secondary displays: 4000 counts (model 72-7732A), 2000 counts (model 72-
7730A),Analog: 40 segments; updates 10 times / second
.
0 C~40 C (32 F~104 F)
-10 C~50 C (14 F~122 F)
75% @ 0 C~30 C below;
50% @ 30 C~40 C:
9V NEDA 1604 or 6F22 or 006P.
In a radio field of 1 V/m below:
Overall Accuracy = Specified Accuracy + 5% of Range
In a radio field of 1 V/m above:
No assigned accuracy is specified.
7"X 3.3"X1.5" (177X 85X40mm).
Approx.340g 12 oz. (including battery)
Model 72-7730A/72-7732A: OPERATING MANUAL
