Tennant S20 - User Manual

Other manuals for Tennant S20

Service Information Manual86 pages

Instruction Bulletin10 pages

Questions and Answers

J
Jacqueline SmithAug 18, 2025
What to do if Tennant S20 Blower has poor sweeping performance?
- K
  Kenneth WrightAug 18, 2025
  Poor sweeping performance in your Tennant Blower can stem from several issues. Check the brush bristles for wear and replace them if needed. Ensure the main and side brushes are properly adjusted. Remove any debris caught in the main brush drive mechanism. Also, verify that the hopper door is fully open and empty the hopper if it's full. Inspect the recirculation flap for damage and replace it if necessary. Finally, check the hopper lip skirts for wear or damage, and replace them if required.
S
sylvia68Aug 20, 2025
Why is my Tennant Floor Machine's sweeping performance poor?
- K
  Karl SantosAug 21, 2025
  Poor sweeping performance in your Tennant Floor Machine can stem from several issues. Check if the brush bristles are worn and replace them if needed. Ensure the main and side brushes are adjusted correctly. Clear any debris caught in the main brush drive mechanism. Also, make sure the hopper door is fully open and empty the hopper if it's full. Inspect the recirculation flap for damage and replace if necessary. Lastly, check the hopper lip skirts for wear or damage, and replace them if needed.
B
Barbara WalkerAug 23, 2025
What to do if Tennant Floor Machine has debris caught in main brush?
- V
  Victoria LopezAug 23, 2025
  If your Tennant Floor Machine has debris caught in the main brush drive mechanism, remove the debris from the drive mechanism.
R
Ryan LopezAug 26, 2025
Why is my Tennant S20 dusting excessively?
- M
  Melissa GomezAug 26, 2025
  Excessive dusting from your Tennant Blower can occur due to several reasons. The hopper door might be partially or completely closed, so make sure to open it. The vacuum fan could be off; if so, move the vacuum and filter shaker lever to the 'Vacuum fan on' position. Also, the hopper dust filter might be clogged; try shaking, cleaning, or replacing the dust filter. Check if the brush skirts and dust seals are worn, damaged, or out of adjustment, and replace or adjust them as needed. The cyclones might be dirty or clogged; clear any blockages. A damaged vacuum hose should be replaced. Additionally, ensure the Thermo Sentry wires are connected, and if the Thermo Sentry has tripped, allow it to cool.
D
David HaneyAug 28, 2025
How to fix excessive dusting with Tennant Floor Machine?
- A
  Andrew SmithAug 28, 2025
  Excessive dusting from your Tennant Floor Machine can occur due to a few reasons. First, ensure the hopper door is fully open. Next, make sure the vacuum fan is on. If the issue persists, shake, clean, or replace the dust filter, as it might be clogged. Inspect and replace or adjust the brush skirts and dust seals if they are worn or damaged. Clear any blockages from the cyclones. Replace the vacuum hose if it's damaged. Check that the Thermo Sentry wires are connected. Finally, allow the Thermo Sentry to cool if it has tripped.
D
Diane MaloneAug 30, 2025
What to do if my Tennant Floor Machine's vacuum hose is damaged?
- T
  Travis HillAug 30, 2025
  If the vacuum hose on your Tennant Floor Machine is damaged, replace it.
S
Sonia FordSep 2, 2025
What to do if hopper is full in Tennant Floor Machine?
- A
  Amber TerrySep 2, 2025
  If the hopper of your Tennant Floor Machine is full, empty it.
C
Chris JacobsSep 7, 2025
Why is the sweeping performance of my Tennant Blower poor?
- S
  Shelly ThomasSep 7, 2025
  If your Tennant Blower's sweeping performance is poor, several factors could be responsible: 1. Worn brush bristles: Replace the brushes. 2. Improperly adjusted main and side brushes: Adjust the main and side brushes. 3. Debris caught in the main brush drive mechanism: Remove any debris from the drive mechanism. 4. Partially or completely closed hopper door: Open the hopper door. 5. Full hopper: Empty the hopper. 6. Damaged recirculation flap: Replace the flap. 7. Worn or damaged hopper lip skirts: Replace the lip skirts.
A
asullivanSep 9, 2025
What to do if Tennant Blower is dusting too much?
- C
  chernandezSep 9, 2025
  If your Tennant Blower is experiencing excessive dusting, start by checking if the hopper door is fully open. If it is, ensure the vacuum fan is on by moving the vacuum and filter shaker lever to the 'Vacuum fan on' position. A clogged hopper dust filter can also cause this issue, so try shaking, cleaning, or replacing it. Also check the Thermo Sentry wires are connected. If equipped, make sure the water tank is full, and if your model has a wet side brush, ensure the dust control switch is turned on and that the filter and nozzle are clean.
B
Benjamin IngramSep 12, 2025
How to fix excessive dusting on a Tennant Blower?
- J
  Jacob EspinozaSep 12, 2025
  To fix excessive dusting on your Tennant Blower, start by opening the hopper door if it's partially or completely closed. Next, ensure the vacuum fan is active by setting the vacuum and filter shaker lever to the 'Vacuum fan on' position. If the hopper dust filter is clogged, shake, clean, or replace it. Also replace vacuum hose if it is damaged. For models with a wet side brush, verify the dust control switch is on and the filter and nozzle are clear.

Summary

Introduction to the Sweeper

Protect the Environment

Guidelines for environmentally safe disposal of materials and components.

Machine Data Entry

Fields for recording machine model, serial number, and installation date.

Intended Use of the Sweeper

Details the machine's purpose, applications, and surfaces it is designed for.

Safety Precautions

Important Safety Instructions

Critical safety warnings and guidelines for operation and servicing.

Safety Warning Labels

Identification and location of safety labels on the machine.

Operation Guide

Machine Components Overview

Identifies and illustrates the main parts of the sweeper.

Controls and Instruments

Details the location and function of all operator controls and displays.

Symbol Definitions

Explains the meaning of various symbols used on the machine's controls.

Installing Batteries

Step-by-step instructions and safety precautions for battery installation.

Operation of Controls

Explains the function of key operational controls like pedals and lights.

Key Control Levers

Details the operation of levers for main cover, steering tilt, and brush adjustments.

Warning Lights and Indicators

Describes the function of lights indicating filter status, hopper, and hydraulic issues.

Operator Interface Controls

Explains controls for power, battery status, hour meter, and lights.

Operator Seat Adjustments

Instructions for adjusting the operator seat and seat belts.

Machine Operation Fundamentals

Describes how the machine works and information on brush types.

While Operating the Machine

Guidelines and safety advice for operating the machine in various conditions.

Pre-Operation Checklist

A comprehensive list of checks to perform before operating the machine.

Starting the Machine

Step-by-step procedure for safely starting the sweeper.

Turning Off the Machine

Procedure for safely shutting down and turning off the sweeper.

Sweeping Procedures

Instructions on how to engage and operate the sweeping functions.

Stopping the Sweeping Process

Steps to properly disengage brushes and vacuum for stopping.

Hopper Management

Procedures for emptying the hopper and related safety checks.

Hopper Support Bar Engagement

Instructions for safely engaging the hopper support bar.

Hopper Support Bar Disengagement

Instructions for safely disengaging the hopper support bar.

Machine Options

Details on optional equipment and their operation.

Vacuum Wand Operation

Instructions for using the optional vacuum wand.

Tower Bumpers (Option)

Information on the function and use of tower bumpers.

Wet Side Brush Dust Control (Option)

Operation and maintenance of the wet side brush dust control system.

Machine Troubleshooting

Guidance for diagnosing and resolving common machine problems.

HEPA Filter Troubleshooting

Troubleshooting table for excessive dust issues with the HEPA system.

Maintenance Procedures

Maintenance Chart

Schedule of routine maintenance tasks, responsibilities, and intervals.

Lubrication Points

Details on lubrication requirements for various machine components.

Front Wheel Bearings Maintenance

Procedure for repacking and adjusting front wheel bearings.

Hydraulics System Maintenance

Information on maintaining the hydraulic system, reservoir, fluid, and hoses.

Hydraulic Fluid Reservoir

Checking and maintaining the hydraulic fluid level in the reservoir.

Hydraulic Fluid Specifications

Details on recommended hydraulic fluid types and specifications.

Hydraulic Hoses Inspection

Procedure for checking hydraulic hoses for wear and damage.

Battery Maintenance

Guidelines for battery care, electrolyte level checks, and connection cleaning.

Checking Electrolyte Level

Procedure for checking and maintaining electrolyte levels in flooded batteries.

Maintenance-Free Batteries

Specific maintenance requirements for maintenance-free batteries.

Checking Connections and Cleaning

Procedure for inspecting and cleaning battery connections.

Charging the Batteries (Off-Board Charger)

Instructions for charging the machine's batteries using an off-board charger.

Electrical Components

Information on fuses, relays, and circuit breakers.

Fuses and Relays

Details on fuse protection and relay functions within the electrical system.

Circuit Protection and Motors

Information on circuit breakers for protection and electric motor maintenance.

Belt Maintenance

Procedures for checking tension and wear on machine belts.

HEPA Filtration System Maintenance

Maintenance procedures for the HEPA filtration system.

Hopper Maintenance

Instructions for inspecting and cleaning the machine's hopper.

Hopper Dust Filter

Procedures for replacing and checking the hopper dust filter.

Replacing the Hopper Dust Filter

Step-by-step guide for replacing the hopper dust filter assembly.

Check Dust Filter Seal Height

Procedure to check and adjust the dust filter seal height.

Cleaning the Dust Filter

Methods for cleaning dust filters for standard and HEPA systems.

Standard Filtration System Dust Filter

Cleaning methods for dust filters in standard filtration systems.

HEPA Filtration System Dust Filter

Cleaning methods for dust filters in HEPA filtration systems.

Cyclone Assembly Cleaning

Procedures for cleaning the cyclone assembly components.

Upper Cyclone Chamber Cleaning

Instructions for cleaning the upper cyclone chamber.

Lower Cyclone Chamber Cleaning

Procedures for cleaning the lower cyclone chamber and HEPA option.

Cyclone Perma-Filter Maintenance

Instructions for cleaning and inspecting the cyclone Perma-Filter.

HEPA Filter Housing Inspection

Procedure for inspecting and cleaning the HEPA filter housing.

Main Brush Maintenance

Guidance on checking, replacing, and rotating the main brush.

Replacing or Rotating the Main Brush

Step-by-step instructions for replacing or rotating the main brush.

Brush Pattern Check & Adjustment

Procedures for checking brush patterns and adjusting taper and width.

Side Brush Maintenance

Procedures for replacing, adjusting, and maintaining side brushes.

Replacing the Side Brush

Step-by-step guide for replacing a side brush.

Adjusting the Side Brush Pattern

Instructions on how to adjust the side brush pattern and pressure.

Side Brush Guard Maintenance

Procedure for rotating or replacing the side brush guard.

Skirts, Flaps, and Seals

Inspection and maintenance of various skirts and flaps on the machine.

Hopper Lip Skirt

Checking and replacing the hopper lip skirt for wear.

Brush Door Skirts

Checking and adjusting brush door skirts for proper floor clearance.

Hopper Side Skirt

Checking the hopper side skirt for wear and adjustment.

Rear Skirts

Checking the rear skirts for wear and adjustment.

Seals and Flaps

Inspection of seals and flaps for wear and damage.

Side Brush Dust Control Skirts (Option)

Checking side brush dust control skirts for wear or damage.

Brush Door Seals

Checking brush door seals for wear or damage.

Hopper Seals

Checking hopper seals for wear or damage.

Hopper Access Door Seal

Checking the hopper access door seal for wear or damage.

Miscellaneous Seals and Flaps

Inspection of various seals and flaps on hopper and filter chambers.

Inner Hopper Access Door Seal (Option)

Checking the inner hopper access door seal for wear or damage.

Hopper Door Seals

Checking hopper door seals for wear or damage.

Filter Chamber Inlet Seal

Checking the filter chamber inlet seal for wear or damage.

Cyclonic Chamber and Dust Tray Flaps

Checking cyclonic chamber flaps for wear, damage, and buildup.

Cyclone Cover and Filter Seals

Inspection of cyclone cover and filter seals for wear or damage.

Cyclone Cover Seals

Checking cyclone cover seals for wear or damage.

Cyclone Cover Access Port Seal

Checking the cyclone cover access port seal for wear or damage.

Hopper Dust Filter Cover Seal

Checking hopper dust filter cover seal for wear or damage.

Brakes and Tires

Maintenance checks for brakes, tires, and filter screens.

Brake System Maintenance

Procedure for checking and adjusting the brake system.

Tire Inspection

Checking solid tires for damage.

Rear Wheel Maintenance

Procedure for torquing rear wheel nuts.

Filter Screens Maintenance

Procedure for removing and cleaning filter screens.

Spray Nozzles Adjustment

Instructions for checking and adjusting spray nozzle patterns.

Storing the Water Tank

Guidelines for storing the water tank when not in use.

Machine Transportation

Procedures for pushing, towing, and transporting the machine.

Machine Jacking Procedures

Safety instructions and steps for jacking up the machine.

Storage Information

Recommendations for storing the machine for extended periods.

Freeze Protection for Wet Side Brush System

Steps to protect the wet side brush system from freezing.

Specifications

General Machine Dimensions and Capacities

Table listing overall dimensions, weight, and capacities of the sweeper.

General Machine Performance

Data on speeds, turning radii, ramp inclines, and noise/vibration levels.

Power Type Specifications

Details on battery types, electric motors, and charger specifications.

Steering System Specifications

Information on the steering system's power source and control.

Hydraulic System Specifications

Details on hydraulic reservoir capacity and fluid type.

Braking System Specifications

Information on the types and operation of service and parking brakes.

Tire Specifications

Details on the type and size of the machine's tires.

Machine Dimensions Diagrams

Illustrations showing the machine's dimensions from top, side, and front views.

Tennant S20 Specifications

General

Brand	Tennant
Model	S20
Category	Blower
Language	English

Related product manuals
