4 mm Hex Key
3 mm Hex Key
7. Install the front mudguard
Use a phillips screwdriver to pre-lock the
mudguard lugs to the front fork.
Use a 4 mm Hex Key to fix the mudguard
supports to both sides of the front fork.
Adjust the lengths of the left and right mudguard
supports to the appropriate positions, use a 3 mm Hex
Key to lock the supports, and then tighten the pre-lock
screws of the mudguard lugs.
Phillips Head Screwdriver
16
