PHYSICAL
A. USB Port (top)
B. 6-28V DC Input
C. 10/100/1000 Ethernet port
D. SD/HD/3G-SDI output
E. Reset button
F. SD/HD/3G-SDI input
G. Wi-Fi antennas (top)
H. Mini-B USB port
I. HDMI output
J. HDMI input
K. Warning indicator
L. Network status
M. 3D LUT status
N. Video Status
O. Menu joystick
P. Status joystick
A. USB Port (top)
B. 6-28V DC Input
C. 10/100/1000 Ethernet port
D. SD/HD/3G-SDI input
E. Wi-Fi antennas (top)
F. Mini-B USB port
G. SD/HD/3G-SDI output B
H. Reset button
I. SD/HD/3G-SDI output A
J. Warning indicator
K. Network status
L. 3D LUT status
M. Video Status
N. Menu joystick
O. Status joystick
