BUTTON OPERATION
STATUS JOYSTICK
 (button press): Cycle through status screens: Video, Wi-Fi, Ethernet, USB, and
system info
MENU JOYSTICK
,,,: Select menu items, change status screen on main display, select
characters

,

(button press): Confirm selection, open selected menu
RESET BUTTON
Hold for 3-6 seconds: Reset all network settings
Hold for 10+ seconds: Perform complete factory reset
POWER
COLR uses an OB 302 series LEMO connector (FGG.0B.302.CLADxx)
Pin
Description
1 (Closest to the red dot)
GND
2
+DC (6-28V)
CUSTOM / 3RD PARTY CABLES
• Test the power cable polarity with ONLY the power cable connected to COLR. Do not connect video cables.
• Check the power cable for shorts and proper grounding.
• CAUTION: Using a reverse polarity or improperly-constructed power cable can damage the product and is not covered
under warranty.
SPECIFICATIONS
AUDIO/VIDEO INPUTS
 HDMI: Full Size in/out
 3G-SDI, HD-SDI, SD-SDI: BNC in/out
 Embedded HDMI/SDI audio input
 Embedded HDMI/SDI audio output
SUPPORTED RESOLUTIONS
 1080p23.98/24/25/29.97/30/50/59.94/60
 1080i50/59.94/60
 1080PsF23.98/24/25
 720p50/59.94/60
 480p59.94, 576p50 (HDMI only)
 480i59.94, 576i50
 HDMI input supports 8-bit RGB 4:4:4, 8-bit YCrCb 4:4:4, 12-bit YCrCb 4:2:2
