11
PROTOCOL SUPPORT
Network Protocols TCP/IP, UDP, HTTP, DHCP, NTP, SSL, IGMP
Bonding Up to 6 Devices, Ethernet
Remote Teradek Core
PHYSICAL ATTRIBUTES
Dimensions 1.69”W x 5.22” D x 4.72 H” [43 x 132.6 x 120 mm]
Weight 19.8 0z. (560 g)
Construction Milled Aluminum
INTERFACES
HTTP Feature-rich web UI for configuration and control
Switches On/Off and Reset switch
Expansion 2 x USB 3.0 Type-A
Status LEDs Multiple LEDs for device, wireless, and network statuses
NETWORK
Ethernet 2 x Gigabit Ethernet RJ45 Ports, Auto MDI-X
Modem 4 x 4-pin locking connectors
2 x USB 3.0 Type-A
Wireless (WiFi) 2x2 2.4GHz 802.11b/g/n, max 20dBm per chain
2x2 5GHz 802.11a/n/ac, max 16dBm per chain
Frequency Range 2.412~2.472GHz, 5.180~5.825GHz
Encryption 802.1x, 802,11i, WPA2, WPA and WEP 64/128 TKIP 128bit AES
POWER
Power Input 2-Pin Circular Locking Connector, 12-20V
Internal Battery Type Cylindrical lithium ion battery - up to 7Wh
PoE N/A
Consumption 19W + 3.5W max for connected USB devices
Battery Plates Integrated Gold or V mount battery plate (optional)
ENVIRONMENTAL
Temperature Operating: -10ºC to 50ºC
Storage: -40ºC to 90ºC
Humidity Operating: 5% to 95% (non-condensing)
Storage: Max. 90%
GENERAL
Mounting 1/4”-20 threaded hole,
2 x 4-40 threaded holes
Additional mounting options available
Link Pro
TECHNICAL SPECIFICATIONS
