6
Attach two SMA mount antennas (either compact or high gain) to each Node.
Connect Node(s) to Link Pro using the included 18” 4-pin to 4-pin cables.
Remove the SIM cover plate and insert a SIM card into the slot of each
Node. Replace the cover plate and screw.
1
3
2
Node is a small yet eective cellular
modem solution that provides exceptional
connectivity in regions around the world,
allowing video professionals to broadcast
over 3G, 4G, and 4G LTE networks.
NOTE: Node powers up and connects to
the cellular network automatically when
connected to Link Pro.
Node’s power LEDs should illuminate immediately. The network LEDs will
also illuminate once an Internet connection is established.
4
You can use up to four Teradek
Nodes to increase your bandwidth
and establish an Internet connection
when another connection is
unavailable.
CONNECT NODES TO LINK PRO
Assembly and Power
NODE
Connect each Node to Link Pro
using an 18" 4-pin to 4-pin cable.
Node’s power LED should illuminate
immediately. The network LED will
also illuminate once an Internet
connection is established.
1
2
To Next Page
