Register
Address
Register
Value
Description
0x4011
0x30
Enable the entering of a BLC (black level
calibration) offset.
0x4013
0xCF
BLC offset value.
0x3508
0x03
Increase the analog gain a bit to compensate for
the BLC offset.
0x5000
0x16
Turn off the LENC (lens correction)
compensation. This setting creates a very even
light distribution across the screen.
