⚫ System CD Download Guide
⚫ One D8M Module
⚫ 40-Pin IDC To Box Header Cable
1.2 D8M System CD
The D8M System CD contains all the documents and supporting materials associated
with D8M, including the user manual, reference designs, and device datasheets. Users
can download this system CD from the link: http://d8m.terasic.com/cd.
1.3 Assemble the Camera
Terasic D8M is able to connect on to any FPGA development kit that is equiped with a
2x20 Pin GPIO connector. The pictures below show the connections allowing the D8M
to connect to 3 different Terasic FPGA Boards:
Figure 1-2 Connect the D8M to DE2-115 board’s expansion port
