Is the control panel giving useful information to work?
Yes! It shows on the display all data related to the lifted load
and the boom position
PANEL MONITORING
-Main Working Data Reading on the display
1.2) LIFTED LOAD
Reading in “Tonnes” or “Lbs”, with a decimal point
1.3) MAXIMUM ADMITTED LOAD (According to the selected load table)
Reading in “Tonnes” or “Lbs”, with a decimal point
1.4) WORKING RADIUS
Reading in “Metres” or “Feet”, with a decimal point
1.5) MAIN BOOM ANGLE
Reading in “Degrees”
1.6) BOOM LENGTH
Reading in “Meters” or “Feet”, with a decimal point.
1.7) HEIGHT FROM GROUND
Reading in “Meters” or “Feet”, with a decimal point.
Note: Imperial and U.S. readings are optional and selectable by parameter.
1.3
1.6
1.2
1.4
1.5
1.7
