PANEL SCREENS
-Complementary reading related to the machine functioning
Can the control panel give further useful information
regarding the machine?
Yes, through the graphic display, showing complementary
reading related to the machine.
1.8
ANTI TWO BLOCK ALARM
This message appears when the Anti two block alarm is activated.
The further information displayed on the panel (zone 1.8) are the following :
1)
1.8
OVERLOAD
This message appears when the lifted load has overtaken the maximum load
allowed referring to the load charts table.
2)
1.8
ROPE OVERLOAD
This message appears when the load lifted overtakes the maximum load allowed on
the single rope.
3)
