Fourth Edition • Fourth Printing
Ground Control Panel
1 Red Emergency Stop button
Push in the red Emergency Stop button to
the off position to stop all functions. Pull out
the red Emergency Stop button to the on
position to operate the machine.
2 Key switch for platform/off/ground selection
Turn the key switch to the platform position and
the platform controls will operate. Turn the key
switch to the off position and the machine will be
off. Turn the key switch to the ground position
and the ground controls will operate.
3 Engine start button
Press this button to start the engine.
4 Gasoline/LPG models: Choke button
Press this button to activate the choke.
Diesel models: Glow plug button
Press this button to activate the glow plugs.
5 Platform down button
Press this button and the platform will lower.
6 Engine idle select button with indicator light
Press this button to select the engine idle
setting. Light on indicates high idle is selected.
Light off indicates low idle is selected.
Operator's Manual
Controls
7 Gasoline/LPG models: LPG select button with
indicator light
Press this button to select fuel. Light on
indicates that LPG is selected. Light off
indicates gasoline is selected.
8 LCD readout screen
9 Platform up button
Press this button and the platform will raise.
10 Emergency lowering function enable button
Press this button to activate the emergency
lowering function.
11 20A circuit breaker for system circuit
12 Emergency lowering down button
Press this button to activate the emergency
lowering down function.
13 Lift function enable button
Press this button to activate the lift function.
14 Hour meter
The hour meter displays the number of hours
the machine has operated.
15 LCD readout screen
Screen displays hour meter, voltage, oil
pressure and coolant temperature. Screen
also displays fault codes and other service
information.
Part No. 133564 GS-3384 • GS-3390• GS-4390• GS-5390 21
