Controls
13 Proportional control handle for drive function
Move the control handle in the direction
indicated by the blue arrow on the control
panel and the machine will move in the
direction that the blue arrow points. Move the
control handle in the direction indicated by
the yellow arrow on the control panel and the
machine will move in the direction that the
yellow arrow points.
14 Thumb rocker switch for steer function
Press the left side of the thumb rocker and the
machine will steer to the left.
Press the right side of the thumb rocker and
the machine will steer to the right.
15 Wrist rest
16 Lift function enable button with indicator light
Press this button to enable the lift function.
17 Proportional rocker switch for outrigger
up/down and platform up/down
With the auto level button indicator light on,
move the rocker switch up and the outriggers
will raise. Move the rocker switch down and
the outriggers will lower.
With an individual outrigger enable button
indicator light on, move the rocker switch up
and the outrigger will raise. Move the rocker
switch down and the outrigger will lower.
With the lift function enable button indicator
light on, move the rocker switch up and the
platform will raise. Move the rocker switch
down and the platform will lower.
