Fourth Edition • Fourth Printing
Platform Control Panel
1 Outrigger function enable button with indicator
light
Press this button to activate the individual
outrigger up/down function.
2 Outrigger auto level button
Press this button to activate the auto
level function.
3 Engine start button
Press this button to start the engine.
4 Engine idle select button with indicator light
Press this button to select the engine idle
setting. Light on indicates high idle is selected.
Light off indicates low idle is selected.
5 Gasoline/LPG models: Choke button
Press this button to aid in starting the engine in
cold conditions.
Diesel models: Glow plug button
Press this button to aid in starting the engine in
cold conditions.
6 Gasoline/LPG models: LPG select button with
indicator light
Press this button to select LPG.
Operator's Manual
Controls
7 Horn button
Press this button and the horn will sound.
Release the button and the horn will stop.
8 Generator select button with indicator light
Press this button to turn the generator on.
Indicator light will be on. Press the button
again to turn the generator off.
9 Machine on incline button with indicator light:
Low speed operation for inclines
Press this button to select low speed operation
for inclines.
10 Green power light/Red error indicator light
Green power light is on when Red Emergency
Stop button is pulled out to the on position.
If red error indicator light is on, push in and pull
out the Red Emergency Stop button to set the
system. If the light stays red, tag and remove
the machine from service.
11 Red Emergency Stop button
Push in the red Emergency Stop button to the
off position to stop all functions and turn the
engine off. Pull out the red Emergency Stop
button to the on position to operate the
machine.
12 Function enable switch
Press and hold the function enable switch to
enable the drive function.
Part No. 133564 GS-3384 • GS-3390• GS-4390• GS-5390 23
