Fourth Edition • Fourth Printing Operator's Manual
Outrigger Operation (if equipped)
1 Position the machine below the desired work
area.
Note: The engine must be running for
the outriggers to operate.
2 Push and hold the auto level button.
3 Activate the up/down rocker switch in the down
direction. The outriggers will extend and level
the machine. A beep will sound when the
machine is level.
The indicator light on the lift function
enable button will turn red when one but
not all outriggers are down. All drive and
lift functions are disabled.
The light turns green on the lift function enable
button and on the individual outrigger buttons
when all the outriggers are in firm contact with
the ground.
The drive function is disabled while the outriggers
are down.
To control individual outriggers
1 Push and hold one or more outrigger buttons.
2 Active the outrigger up/down rocker switch
in the desired direction to level the machine.
Operating Instructions
After Each Use
1 Select a safe parking location—firm level
surface, clear of obstruction and traffic.
2 Lower the platform.
3 Turn the key switch to the off position and
remove the key to secure from unauthorized
use.
Part No. 133564 GS-3384 • GS-3390• GS-4390• GS-5390 43
