Operator's Manual First Edition • Third Printing
Operating Instructions
50 GS
™
-1432m • GS
™
-1932m • GS
™
-1932m Lite Part No. 1308591GT
Observe and Obey:
 Lift Tools Panel Carrier must be mounted on
the left side of the platform.
 Lift Tools Panel Carrier cannot be used with
any other option, except Lift Tools Work Tray.
 Lift Tools Panel Carrier must not obstruct the
platform controls or the platform entrance.
 Lift Tools Panel Carrier is restricted to indoor
use only.
 The platform is restricted to one person when
Lift Tools Panel Carrier option is in use.
 Be sure that the Lift Tools Panel Carrier is
secured to the platform.
Panel Carrier Installation
1 Hang carrier (1) onto the bottom flange of the
platform, on the left side.
2 Secure the carrier with 2, 1/4" carriage bolts
(2) and lock nuts (3).
3 Attach mounting tab (8) to front rail post. A
3/8" bolt (4) and nut (7) are provided.
4 Attach strap (5) to mounting tab.
Installation of Panel Carrier Strap
1 Open the clamp and install it on the mounting
tab with the 1/4" x 0.75" bolt (6).
2 Install the strap assembly end plate onto the
bolt.
3 Insert the bolt through the other side of the
clamp.
Panel Cradle Operation
1 Place the load so that it rests in the center of
the Lift Tools Panel Carrier.
2 Secure the load to the platform using the strap
by passing it in front of the load and securing
the S-hook around the upper rail near the rear
of the platform.
3 Gently push and pull on the load to make sure
the panel carrier and load are secure.
4 Keep the load secured when the machine is
moving.
The Lift Tools Panel Carrier assembly weighs
22 lbs/10 kg.
Maximum Lift Tools Panel Carrier Capacity
Load Chart
GS
-1432m, GS-1932m, GS-1932m
Lite
100 l
bs
45.4 k
g
Tip-over hazard. The weight of the Lift Tools
Panel Carrier assembly and the load in the Lift
Tools Panel Carrier assembly will reduce the
rated platform capacity of the machine and
must be factored into the total platform load.
Tip-over hazard. The weight of the Lift Tools
Panel Carrier assembly and the load in the Lift
Tools Panel Carrier may limit the maximum
number of occupants in the platform.
Maximum panel size allowed: 4 feet high x
8 feet long. See load chart for weight capacity.
Do not operate unless you are adequately
instructed and are aware of all hazards associated
with lifting panels.
Do not cause a horizontal force or side load to
machine by raising or lowering a fixed or
overhanging load.
Do not transport the unit with Lift Tools Panel
Carrier installed. Remove entire assembly before
transporting the unit.
