Technical Specifications3
32/112 TL160
Operating Manual 12.9.08 Version 1.0
3.12 Dimensions and weights
Dimensions and weights
Operating weight, standard equipment
1
approx. 9200 kg
Total length, standard bucket on ground (quick-attach system / directly mounted) 6730 / 6690 mm
Total width 2300 mm
Total height (cabin roof) 3030 mm
Wheel base 2760 mm
Tire tread with, FR / RR 1780 mm
Rear overhang angle 35°
Ground clearance below propeller shaft 540 mm
Turning radius at outside edge of bucket in transport position (quick-attach system/ directly mounted) 5410 / 5395 mm
Turning radius at inside edge of tires 2665 mm
Tab. 15 Dimensions and weights - Specifications refer to general-purpose bucket and 15.5 R 25 tires
1
according to ISO 6016
Front loader installation Quick-attach
system
Direct mounting
Width of bucket 2300 mm 2300 mm
Capacity to DIN/ISO 7546 (max. density = 1.8 t/m
3
) approx. 1.5 m³ approx. 1.6 m³
Payload in bucket 2700 kg 2880 kg
Dump height at 45° dump angle 2890 mm 2930 mm
Dump reach at max. dump height 910 mm 880 mm
Max. bucket hinge pin height 3895 mm 3895 mm
Tilt-back angle 50° 50°
Dump angle at max. dump height 45° 45°
Digging depth, horizontal bucket 100 mm 75 mm
Lift capacity at ground level
1
85.5 kN 85.5 kN
Ripping force at cutting edge of bucket
1
83.2 kN 86 kN
Tipping load, straight
1
6575 kg 6575 kg
Tipping load, articulated
1
5780 kg 5780 kg
Work cycle time, "Lift" 5.7 s 5.7 s
Work cycle time “Dumping in uppermost position – IN” 3.7 s 3.7 s
Work cycle time “Dumping in uppermost position – OUT” 2.0 s 2.0 s
Work cycle time “Dumping in upper position” 1.4 s 1.4 s
Tab. 16 Dimensions and weights - Specifications refer to general-purpose bucket and 15.5 R 25 tires - Stability conforms to
DIN 24094
1
according to ISO 8313
Buckets Width
mm
Capacity, heaped
1
m
3
Max. density (γ)
t/m
3
Bucket 2300 1.5 / 1.6 1.8
Bucket with bolt-on cutting edge 2300 1.5 /1.6 1.8
Earth bucket 2300 1.7 / 1.8 1.6
Earth bucket with bolt-on cutting edge 2300 1.7 / 1.8 1.6
Multi-purpose bucket 2300 1.25 / - 1.6
Multi-purpose bucket with bolt-on cutting edge
2300 1.25 / - 1.6
Light-material bucket with bolt-on cutting edge
2300 2.2 / - 1.2
Light-material bucket with bolt-on cutting edge
2500 2.6 / - 0.8
High-tip bucket 2300 1.5 1.2
Tab. 17 Bucket dimensions
1
Quick-attach system / directly mounted
