Terex TL160 - Page 95

Care and Maintenance 7
95/112TL160
Operating Manual 12.9.08 Version 1.0
7.8.13 Replacing the breather
• Remove the breather (71/2) and dispose of
according to regulations.
• Clean the screen (72/3) and check for damage;
replace if required.
• Screw in new breather (72/1) with O-ring (72/2)
and tighten by hand.
Machine damage
due to dirt reaching the uncovered hydraulic
oil tank.
• Before starting, clean all parts above the
tank.
Fig. 71 Hydraulic oil tank
L864-724
2
Attention
• The breather must be replaced if it is dirty,
for example due to hydraulic oil vapor.
Fig. 72 Replacing the breather
1
L864-725
2
3
