90-B. PUMP REPAIR - PARTS LOCATION
-----
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
-----
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
1.00
4.00
4.00
2.00
4.00
4.00
4.00
2.00
2.00
1.00
4.00
4.00
1.00
PUMP,DUAL SUCTION 3.19&1.24 CU
MOUNTING FLANGE
HOUSING, CONNECTION, DUAL PUMP
COVER, FLANGE, DUAL SUC PUMP
HOUSING, GEAR, FRT PUMP ASY
GEAR HOUSING, DUAL SUC PUMP
SET, GEAR SHAFT, FRT PUMP ASY
SET, GEAR, DUAL SUC PUMP
SHAFT, CONNECT, DUAL SUC PUMP
SCREW, CAP, DUAL SUC PUMP
STUD, FRT PUMP ASY,3.91&1.24CU
SCREW, DRIVE, FRT PUMP ASY
NUT 5/8 NC PLB
DOWEL PIN, PUMP, HYDRO 15/10
DOWEL, PIN, DUAL PUMP, REAR
THRPL, FRT PUMP ASY
THRPL, DUAL PUMP, REAR
PLUG
WASHER
WASHER
KIT, SEAL, DUAL SUC PUMP
