1.6 Package Ov
erview
LCD Display
Power Cord
DC Power Supply
OSD Key pad
DP cable
VGA cable
!
Warming!
This
product
is
intended
to
be
supplied
by
a
Listed
Power
Adapter
or
DC
power
source,
rated
12
Vdc,
1.0A
minimum,
Tma
=
50
degree
C
minimum,
and
the
altitude
of
operation
=
3048m
minimum.
If
it
nee
ds
further
assistance
with
purchasing the power source, please contact to TES for further information.
